Ib qho HB6 Linear LED High Low Bay fixture yog hom teeb pom kev zoo tsim los rau kev lag luam thiab kev lag luam qhov chaw uas lub qab nthab qhov siab sib txawv, yog li lub sij hawm "high low bay." "HB6" tej zaum yuav hais txog qhov loj los yog daim ntawv ntawm cov teeb pom kev zoo, qhia tias nws yog ib feem ntawm cov koob lossis kev faib tawm hauv cov khw muag khoom.
Linear LED fixtures yog tus cwj pwm los ntawm lawv cov duab elongated, uas muaj ntau lub LEDs nyob rau hauv ib tug ncaj configuration. Cov teeb no yog lub zog txuag, ruaj khov, thiab muaj qhov zoo nkauj zoo nkauj uas haum rau ib puag ncig uas yuav tsum muaj teeb pom kev zoo. High Low Bay fixtures muaj ntau yam vim hais tias lawv tuaj yeem ntsia tau rau hauv cov cheeb tsam uas muaj lub qab nthab siab (bays) nrog rau qhov siab ntawm qab nthab, ua rau lawv hloov tau rau ntau lub tsev rau khoom, kev tsim khoom, lossis chaw muag khoom.
Cov khoom siv no feem ntau muaj cov kev xaiv kho kom haum kom haum rau lub qab nthab qhov siab sib txawv thiab tuaj yeem suav nrog cov yam ntxwv xws li cov lus tsa suab, lub peev xwm dimming, thiab xim kub hloov kho kom haum rau cov teeb pom kev zoo tshwj xeeb. Linear LED High Low Bay fixtures yog tsim los kom xa cov lumen siab, ua kom muaj qhov ci txaus thoob plaws qhov chaw qhib loj.
Thaum xaiv HB6 Linear LED High Low Bay fixture, kev txiav txim siab yuav tsum suav nrog cov lumens (lub teeb tso zis) xav tau, xim rendering Performance index (CRI) rau qhov tseeb xim sawv cev, zoo ntawm cov ntaub ntawv rau durability, thiab warranty muab los ntawm cov chaw tsim tshuaj paus. Nws tseem ceeb heev kom ua raws li cov cai hluav taws xob thiab cov qauv.
Vim li cas thiaj xaiv peb
Pab neeg tshaj lij
Peb muaj cov pab pawg R & D muaj zog uas ua haujlwm ze rau Kev Lag Luam thiab Kev Muag Khoom, thiab kev tswj hwm nruj thiab cov chaw ua haujlwm kom zoo.
Khoom siv Advanced
Ntau tshaj 600.
Kev paub nplua nuj
Ntau tshaj 8 tus kws tshaj lij engineers nrog qhov nruab nrab 8 xyoo kev ua haujlwm, los ntawm ntau qhov chaw, xws li optics desgn, electronics, mechanical, thermal ects, koom tes nrog cov khoom lag luam.
One-Stop Solution
Peb cov kev daws teeb meem yog tsim los siv lub teeb pom kev zoo software thiab bespoke technology uas ua kom peb xa cov kev txuag nyiaj ntau tshaj plaws, cov teeb pom kev zoo uas nyob rau hauv lem yuav xa qhov siab tshaj plaws rov qab los rau koj qhov project.
Daim ntawv thov ntawm HB3 Eco UFO High Bay
HB3 Eco UFO High Bay yog ib hom LED teeb pom kev zoo tsim los siv rau hauv qhov chaw loj hauv tsev uas yuav tsum tau muaj teeb pom kev zoo, xws li warehouses, factories, gyms, thiab cov khw muag khoom loj. Lub npe "UFO" feem ntau yog hais txog cov duab ntawm qhov sib tw, uas zoo li lub dav hlau ya. Nov yog qee cov ntsiab lus ntawm daim ntawv thov HB3 Eco UFO High Bay teeb:
Zog Efficiency
HB3 Eco UFO High Bay teeb siv LED thev naus laus zis, uas paub txog nws lub zog ua haujlwm siab piv rau cov teeb pom kev zoo ib txwm muaj xws li hlau halide lossis high-pressure sodium teeb. Qhov no ua rau lawv raug nqi zoo nyob rau lub sijhawm ntev vim lawv siv hluav taws xob tsawg thiab txo cov nqi hluav taws xob.
Luminaire Design
Tus tsim ntawm HB3 Eco UFO High Bay feem ntau muaj qhov zoo nkauj, niaj hnub saib, uas tuaj yeem ua kom zoo nkauj ntawm cov chaw ua haujlwm niaj hnub. Cov khoom siv feem ntau yog ua los ntawm cov khoom siv ruaj khov kom tiv taus qhov hnyav hnyav thiab tiv taus corrosion thiab kev puas tsuaj.
Teeb pom kev zoo
Cov khoom siv no muab kev nthuav dav dav ntawm cov teeb pom kev zoo sib xws, uas yog qhov tseem ceeb rau kev tswj kom pom kev pom thiab kev nyab xeeb nyob rau hauv qhov chaw siab. Kev siv zog siab thiab txawm tias qhov sib faib ntawm lub teeb pab tiv thaiv qhov tsaus ntuj thiab ntxoov ntxoo uas tuaj yeem ua rau muaj xwm txheej.
Kev teeb tsa
HB3 Eco UFO High Bay teeb yog feem ntau ncaj nraim rau kev teeb tsa, nrog rau ntau yam kev xaiv mounting muaj, nrog rau kev ncua cables, chains, lossis hooks. Lawv kuj tuaj yeem nrog cov hlua kho tau los tso cai rau ntau lub kaum sab xis ntawm lub teeb pom kev zoo. Kev txhim kho kev cob qhia yog pom zoo kom ua raws li cov cai hluav taws xob thiab cov qauv.
Kev Tswj Kub Kub
LED teeb ua kom muaj cua sov tsawg dua li cov teeb pom kev zoo ib txwm muaj, uas tuaj yeem txhim kho kev tswj xyuas thermal hauv qhov khoom siv thiab txuas ntxiv lub neej ntawm LED chips. Kev ua kom sov zoo yog qhov tseem ceeb rau kev tswj xyuas kev ua haujlwm thiab kev ua haujlwm ntev ntawm lub teeb pom kev zoo.
Durability thiab Longevity
LED teeb muaj lub neej ntev dua li ntau lwm hom teeb pom kev zoo, uas txhais tau hais tias HB3 Eco UFO High Bay tuaj yeem muab kev teeb pom kev zoo rau ntau xyoo yam tsis tas yuav hloov ntau zaus. Qhov no txo cov nqi txij nkawm thiab kev poob qis uas cuam tshuam nrog teeb pom kev tsis ua haujlwm.
Tswj kev xaiv
Qee qhov HB3 Eco UFO High Bay fixtures tuaj yeem suav nrog kev tswj xyuas qib siab xws li kev sau hnub ci, cov neeg nyob hauv sensors, lossis lub peev xwm dimming. Cov yam ntxwv no tuaj yeem txhim kho kev txuag hluav taws xob ntxiv los ntawm kev kho lub teeb tso zis raws li qhov chaw nyob ib puag ncig lossis muaj lub teeb pom kev zoo.
Ua raws li Cov Qauv
High-zoo HB3 Eco UFO High Bay fixtures ua raws li ntau yam kev lag luam qauv thiab ntawv pov thawj, xyuas kom meej tias lawv ua tau raws li kev nyab xeeb thiab kev ua tau zoo. Qhov no suav nrog cov ntawv pov thawj rau kev siv hauv qhov chaw muaj kev phom sij yog tias muaj.
Hauv cov ntsiab lus, HB3 Eco UFO High Bay yog lub teeb pom kev zoo ntau yam rau cov chaw sab hauv tsev siab uas yuav tsum tau ua kom muaj txiaj ntsig zoo, teeb pom kev zoo nrog kev saib xyuas tsawg thiab cov nqi khiav lag luam. Nws muab cov kev zoo nkauj niaj hnub nrog cov cuab yeej teeb pom kev zoo kom xa cov teeb pom kev zoo thiab txuag hluav taws xob.
Yuav Ua Li Cas Koj Loj Led High Bay Teeb?
Sizing LED high bay teeb yuav tsum xav txog ntau yam los xyuas kom meej lub teeb pom kev zoo hauv ib qho chaw tshwj xeeb. Nov yog qee qhov kev txiav txim siab tseem ceeb thaum ntsuas LED siab bay teeb:
Space Dimensions:Txiav txim siab qhov ntev ntawm thaj chaw uas yuav tsum tau teeb pom kev zoo, suav nrog qhov dav, qhov ntev, thiab qhov siab ntawm chav tsev lossis chaw ua haujlwm.
Lub teeb pom kev xav tau:Xav txog qhov xav tau lub teeb pom kev zoo lossis lub teeb pom kev xav tau rau kev ua haujlwm lossis kev ua haujlwm hauv qhov chaw. Qhov no tuaj yeem ua raws li cov qauv kev lag luam lossis cov kev cai tshwj xeeb.
Mounting Qhov siab:Ntsuas qhov siab ntawm qhov LED siab bay teeb yuav raug teeb tsa. Qhov siab mounting siab feem ntau xav tau lub teeb muaj zog dua kom ua tiav qhov xav tau illumination.
Lub teeb faib qauv:Saib ntawm lub teeb faib qauv ntawm LED high bay teeb. Qee lub teeb muaj lub kaum sab xis dav dua, thaum lwm tus muab cov teeb pom kev zoo dua. Xaiv cov qauv uas zoo tshaj plaws haum rau thaj chaw uas tau teeb.
Wattage thiab Lumens:Xav txog cov wattage thiab lumens tso zis ntawm LED siab bay teeb. Ntau dua wattage feem ntau qhia ntau lub teeb pom kev, tab sis kev siv hluav taws xob kuj tseem yog qhov tseem ceeb.
Chaw tsim tshuaj paus Specifications:Xa mus rau cov chaw tsim khoom cov lus qhia tshwj xeeb thiab cov lus pom zoo rau cov lus qhia sizing. Lawv feem ntau muab cov ntaub ntawv hais txog lub teeb pom kev zoo, lub kaum sab xis ntawm lub teeb, thiab qhov sib txawv ntawm lawv cov teeb tshwj xeeb.
Lighting Design Software:Qee lub teeb pom kev zoo tsim software tuaj yeem pab hauv kev suav cov teeb pom kev uas xav tau thiab qhov loj me raws li qhov chaw qhov ntev thiab teeb pom kev zoo.
Nws feem ntau tau txais txiaj ntsig los sab laj nrog tus kws tshaj lij teeb pom kev zoo lossis siv cov cuab yeej tsim teeb pom kev zoo kom raug qhov loj ntawm LED siab bay teeb. Lawv tuaj yeem coj mus rau hauv tus account yam xws li kev xav ntawm qhov chaw, lub teeb xim kub, thiab cov haujlwm tshwj xeeb xav tau los ua kom pom kev pom kev ua haujlwm zoo.
Qhov siab ntawm high bay teeb tuaj yeem sib txawv nyob ntawm qhov kev thov tshwj xeeb thiab tsim. Feem ntau, cov teeb pom kev zoo yog tsim los rau nruab rau ntawm lub qab nthab siab dua, feem ntau yog li ntawm 10 feet (3 meters) txog 40 feet (12 meters) lossis ntau dua.
Qhov siab ntawm qhov teeb pom kev siab siab yog nyob ntawm ntau yam, suav nrog lub qab nthab qhov siab ntawm qhov chaw, qhov xav tau ntawm lub teeb pom kev zoo, thiab lub teeb faib qauv ntawm cov khoom siv. Qee qhov xwm txheej, cov teeb pom kev siab tuaj yeem raug teeb tsa ntawm qhov siab qis dua yog tias qhov chaw muaj lub qab nthab qis lossis cov teeb pom kev tshwj xeeb xav tau.
Nws yog ib qho tseem ceeb uas yuav tsum nco ntsoov tias qhov siab ntawm high bay teeb kuj tuaj yeem cuam tshuam los ntawm lwm yam xws li mounting txoj kev, hom teeb fixture, thiab lub teeb pom kev zoo. Qee lub teeb ci ntsa iab tau kho tau hauv qhov siab, tso cai rau kev yooj yim hauv kev teeb tsa.
Thaum txiav txim siab qhov siab tsim nyog rau high bay teeb, nws yog qhov zoo tshaj plaws los txiav txim siab txog cov cai tshwj xeeb ntawm qhov chaw thiab sab laj nrog tus tsim teeb pom kev zoo lossis cov chaw tsim khoom. Lawv tuaj yeem muab kev taw qhia raws li lub qab nthab qhov siab, lub hom phiaj teeb pom kev zoo, thiab cov kev cai tshwj xeeb lossis cov qauv uas yuav tsum tau ua.
Yuav Ua Li Cas Xaiv Led High Bay Teeb?
Xaiv txoj cai LED siab bay lub teeb yuav tsum xav txog ntau yam los xyuas kom meej tias cov teeb pom kev zoo muab qhov tsim nyog illumination thiab kev ua tau zoo rau daim ntawv thov. Nov yog qee yam tseem ceeb uas yuav tsum xav txog thaum xaiv LED siab bay teeb:
Lub teeb tso zis
Lub teeb tso zis ntawm LED high bay teeb fixture yog ib qho tseem ceeb rau kev txiav txim siab, raws li nws cuam tshuam rau theem illumination ntawm qhov chaw. Nws raug nquahu kom xaiv cov khoom siv nrog lub siab lumen tso zis kom ntseeg tau tias muaj teeb pom kev txaus.
Xim kub
Cov xim kub ntawm LED teeb fixture tuaj yeem cuam tshuam rau ambiance thiab mus ob peb vas ntawm qhov chaw. Xaiv cov xim kub uas tsim nyog rau daim ntawv thov, xws li sov dawb (2700-3000K) rau qhov chaw caw ntau dua lossis txias dawb (5000-6500K) rau qhov ci ntsa iab, kho kom zoo dua.
Beam Angle
Lub kaum sab xis ntawm LED high bay teeb fixture cuam tshuam rau lub teeb faib qauv thiab kev pab them nqi cheeb tsam. Xaiv lub teeb pom kev zoo nrog lub kaum sab xis dav kom muab cov teeb pom kev zoo thoob plaws hauv qhov chaw lossis lub kaum sab xis nqaim rau lub teeb pom kev zoo dua.
Zog Efficiency
LED high bay teeb muaj lub zog ntau dua li cov teeb pom kev zoo ib txwm muaj, tab sis nws tseem ceeb heev uas yuav tsum xaiv cov khoom siv nrog kev ua haujlwm siab kom txo tau lub zog noj thiab txuag nyiaj dhau sijhawm.
Durability
LED high bay teeb yog raug rau cov plua plav, av, thiab noo noo ntau ntau. Xaiv cov khoom siv uas muaj qhov ntsuas ruaj khov uas tsim nyog rau ib puag ncig kom ntseeg tau tias kev ua haujlwm ntev.
Mounting Options
Cov kev xaiv mounting muaj rau LED high bay teeb fixture tuaj yeem cuam tshuam kev teeb tsa thiab kev saib xyuas. Xaiv cov fixtures nrog yooj yim-rau-nruab mounting brackets thiab swivel xaiv los ua installation thiab txij nkawm yooj yim dua.
Nqe
LED high bay lub teeb fixtures tuaj yeem sib txawv ntawm tus nqi nyob ntawm seb cov teeb pom kev zoo, xim kub, thiab kav ntev. Thaum nws yog ib qho tseem ceeb los xav txog tus nqi, nws tseem ceeb heev uas yuav tau xaiv cov khoom siv uas tsim nyog rau kev ua tau zoo thiab teeb pom kev zoo rau daim ntawv thov.
Chaw tsim tshuaj paus
Xaiv ib lub chaw tsim khoom nrog lub koob npe nrov rau kev ua tau zoo thiab kev ntseeg siab tuaj yeem pab xyuas kom meej tias LED siab bay teeb fixture yuav muab kev ua haujlwm ntev. Tshawb xyuas cov chaw tsim khoom WARRANTIES thiab cov neeg siv khoom txhawb nqa kom ntseeg tau tias cov khoom siv yuav raug txhawb yog tias muaj teeb meem tshwm sim.
Puas High Bay LED Teeb Kub Kub?
High Bay LED teeb, zoo li txhua yam khoom siv hluav taws xob, tsim kom muaj cua sov ua cov khoom siv los ntawm lawv txoj haujlwm. Txawm li cas los xij, LED thev naus laus zis yog qhov muaj zog ntau dua li cov khoom siv teeb pom kev zoo xws li fluorescent, incandescent, lossis high-intensity discharge (HID) teeb. Qhov no txhais tau hais tias LEDs hloov ntau dua ntawm cov hluav taws xob hluav taws xob uas lawv siv rau hauv qhov pom kev pom thiab tsawg dua rau hauv cov cua sov, uas ua rau qis dua qhov kub thiab txias piv rau lawv cov neeg ua ntej.
Txawm hais tias qhov hluav taws xob qis qis, nws tseem yog ib qho tseem ceeb rau cov tuam txhab lag luam los tswj cov cua sov uas tsim los ntawm High Bay LED teeb kom zoo thiab ua haujlwm tau zoo. Kev tswj cua sov yog hais los ntawm ntau lub tswv yim tsim:
Thermal Interface Materials (TIMs):High-quality TIMs yog siv los sau qhov sib txawv ntawm LED nti thiab lub dab dej kub, muab cov thermal conductivity zoo.
Thaum tshav kub kub Sinks:Kev siv hluav taws xob zoo yog qhov tseem ceeb hauv kev faib cov cua sov uas tsim los ntawm LEDs. Cov no feem ntau yog ua los ntawm txhuas lossis lwm yam ntaub ntawv uas muaj thermal conductivity thiab tej zaum yuav feature fins los yog lwm yam lug txhim khu qhov chaw nto kom zoo dua tshav kub dissipation.
Luminaire Design:Kev tsim cov teeb pom kev zoo kuj tuaj yeem ua lub luag haujlwm hauv cov cua sov dissipation. Kev ua pa kom raug thiab cua ntws nyob ib puag ncig lub teeb tuaj yeem pab ua kom qhov kub thiab txias.
LED Zoo:Cov LEDs zoo dua muaj qhov ua tau zoo dua thiab ua kom muaj cua sov tsawg. Kev nqis peev nyob rau hauv hwm LED chips tuaj yeem ua rau lub tshuab ua kom txias dua.
Cov tsav tsheb:Lub zog hluav taws xob lossis tus tsav tsheb rau lub teeb ci LED tuaj yeem cuam tshuam rau kev tsim hluav taws xob. High-efficiency tsav tsheb hloov hluav taws xob ntau rau hauv lub teeb siv tau, txo cov cua sov pov tseg.
Txawm hais tias nrog cov kev ntsuas no, nws yog ib txwm ua rau High Bay LED teeb ua kom sov rau qhov kov thaum ua haujlwm. Txawm li cas los xij, lawv yuav tsum tsis txhob kub heev rau qhov uas nws ua rau muaj kev nyab xeeb los yog ua rau lub neej luv luv ntawm LEDs thiab lwm yam khoom. Kev saib xyuas tsis tu ncua thiab ua kom ntseeg tau tias cov khoom siv tau raug teeb tsa raws li cov chaw tsim khoom cov lus pom zoo tuaj yeem pab tswj kev ua haujlwm kom zoo.
Linear txhais li cas nrog LED teeb?
Nyob rau hauv cov ntsiab lus ntawm LED teeb, "linear" yog hais txog ib tug style ntawm teeb pom kev zoo fixture uas muaj ib tug ntev, nqaim duab. Linear LED fixtures feem ntau yog siv los muab kev teeb pom kev zoo nyob rau hauv txoj kev ncaj los yog hla thaj chaw loj. Lawv tuaj nyob rau hauv ntau qhov ntev, los ntawm ob peb nti mus rau ob peb taw, thiab tuaj yeem ntsia tau rau hauv qab nthab, tshem tawm los ntawm sab saud, lossis ntsia rau ntawm phab ntsa.
Linear LED fixtures yog nrov rau kev lag luam thiab kev lag luam daim ntawv thov vim lawv muaj ntau yam zoo:
Uniform Light Distribution:Linear fixtures faib lub teeb sib npaug ntawm lawv qhov ntev, uas yog qhov zoo tagnrho rau kev tsim kom muaj qhov chaw ua haujlwm zoo lossis qhov chaw muag khoom.
Flexibility hauv Design:Lawv tuaj yeem ntsia tau rau hauv ntau yam kev teeb tsa, xws li kev khiav mus tas li lossis cov ntu ib leeg, kom haum rau cov qauv tsim vaj tsev sib txawv thiab cov teeb pom kev zoo.
Efficiency thiab Nqi-Effectiveness:Zoo li lwm yam kev daws teeb meem LED teeb pom kev zoo, linear LEDs yog lub zog txuag hluav taws xob, uas ua rau txo qis kev siv hluav taws xob thiab txo nqi hluav taws xob thaum lub sijhawm.
Niaj hnub Aesthetics:Linear LED fixtures muaj ib tug sleek, huv si tsos uas yuav ntxiv niaj hnub sab hauv tsim.
Versatility:Lawv tuaj yeem siv rau ntau qhov chaw, suav nrog chaw ua haujlwm, tsev kawm ntawv, tsev kho mob, tsev loj, thiab chaw tsim khoom.
Linear LED fixtures kuj tseem tuaj yeem suav nrog cov yam ntxwv ntxiv xws li dimmability, hloov xim kub, thiab kev teeb pom kev kub ntxhov. Thaum xaiv cov teeb ci LED, nws yog ib qho tseem ceeb uas yuav tsum xav txog yam xws li lumen tso zis, xim kub, ntev kev xaiv, thiab cov kev xav tau tshwj xeeb ntawm qhov chaw raug teeb pom kev zoo.
Dab tsi yog qhov txawv ntawm Linear Lighting?
Linear teeb pom kev zoo hais txog cov teeb pom kev zoo uas ntev thiab nqaim hauv cov duab, thiab lawv muaj nyob rau hauv ntau hom kom haum rau ntau yam kev siv thiab kev nyiam tsim. Nov yog qee hom kev teeb pom kev zoo linear:
LED Linear Tubes
LED linear tubes yog lub teeb ntev thiab nqaim uas feem ntau siv hauv kev lag luam thiab kev lag luam. Lawv muab lub teeb ci, teeb pom kev zoo thiab muaj ntau yam xim thiab ua tiav.
LED Linear Panels
LED linear panels yog nyias, lub teeb duab plaub uas feem ntau siv hauv kev lag luam thiab kev siv hauv tsev. Lawv muab txawm tias illumination thiab muaj nyob rau hauv ntau yam xim thiab tiav.
LED Linear Sawb
LED linear strips yog nyias, hloov tau yooj yim teeb uas feem ntau siv rau hauv vaj tse thiab kev lag luam. Lawv tuaj yeem raug txiav kom ntev thiab muaj ntau yam xim thiab ua tiav.
LED Linear Pendants
LED linear pendants yog ntev, dai teeb uas feem ntau siv rau hauv kev lag luam thiab kev siv hauv tsev. Lawv muab txawm tias illumination thiab muaj nyob rau hauv ntau hom thiab tiav.
LED Linear Hauv qab txee teeb
LED linear nyob rau hauv txee teeb yog nyias, lub teeb duab plaub uas feem ntau siv hauv chav ua noj thiab chav dej. Lawv muab cov teeb pom kev ua haujlwm thiab muaj ntau yam xim thiab ua tiav.
LED Linear Phab Ntsa Washer
LED linear phab ntsa washers yog ntev, nqaim teeb uas feem ntau siv los teeb pom kev ntawm phab ntsa thiab cov yam ntxwv ntawm vaj tse. Lawv muab txawm tias illumination thiab muaj nyob rau hauv ntau yam xim thiab tiav.
LED Linear Qab nthab Teeb
LED linear qab nthab teeb yog ntev, nqaim teeb uas feem ntau siv los teeb pom kev lag luam thiab chaw lag luam. Lawv muab lub teeb ci, teeb pom kev zoo thiab muaj nyob rau hauv ntau hom thiab tiav.
LED Linear Kauj Ruam Teeb
LED linear kauj ruam teeb yog nyias, lub teeb duab plaub uas feem ntau siv los teeb cov ntaiv thiab cov kev taug kev. Lawv muab cov teeb pom kev ua haujlwm thiab muaj ntau yam xim thiab ua tiav.
LED Linear Cove Teeb
LED linear cove teeb yog nyias, cov teeb duab plaub uas feem ntau siv los teeb pom kev thiab niches hauv kev tsim vaj tsev. Lawv muab txawm tias illumination thiab muaj nyob rau hauv ntau yam xim thiab tiav.
LED Linear Track Teeb
LED linear khiav teeb yog ntev, nqaim teeb uas feem ntau siv los teeb pom kev lag luam thiab thaj chaw nyob. Lawv tuaj yeem hloov kho kom muab cov teeb pom kev sib txawv thiab muaj nyob rau hauv ntau hom thiab tiav.
Yuav ua li cas koj dai High Bay LED teeb?
Hanging high bay LED teeb feem ntau suav nrog cov kauj ruam hauv qab no:
Kev npaj:Ua ntej pib lub installation, txiav txim siab qhov chaw thiab qhov siab qhov twg lub teeb yuav raug teeb tsa. Ntsuas thaj tsam kom paub tseeb tias lub teeb yuav muab kev pab txaus. Tsis tas li ntawd, xav txog cov khoom siv hluav taws xob uas twb muaj lawm thiab seb nws puas yuav tsum tau hloov kho lossis hloov kho kom haum rau cov khoom siv tshiab.
Kev Tiv Thaiv Kev Nyab Xeeb:Xyuas kom meej tias lub hwj chim mus rau thaj chaw uas lub teeb ci siab yuav raug muab tua kom tsis txhob muaj hluav taws xob. Siv cov cuab yeej tiv thaiv tus kheej tsim nyog (PPE), xws li hnab looj tes, tsom iav, thiab lub kaus mom tawv.
Npaj Ceiling:Ntxuav thaj chaw uas lub teeb yuav raug dai. Yog tias muaj cov khoom siv uas twb muaj lawm lossis cov khib nyiab, tshem tawm kom zoo. Yog tias cov khoom siv qab nthab yog phab ntsa ntub dej, nco ntsoov nrhiav cov joists lossis studs los txhawb qhov hnyav ntawm lub teeb ci siab.
Mounting Bracket:Nruab lub mounting bracket uas tuaj nrog lub siab bay teeb raws li cov chaw tsim khoom cov lus qhia. Qhov no feem ntau yog txuas lub bracket rau cov joists los yog siv toggle bolts los yog expansion anchors yog tias tsis muaj ntoo los tuav lub bracket.
Kev xaim:Khiav cov hluav taws xob xaim hluav taws xob los ntawm qhov chaw sib txuas ze tshaj plaws mus rau qhov chaw ntawm lub teeb ci siab. Nco ntsoov ua raws li cov cai hauv zos thiab cov qauv hluav taws xob. Siv cov kav dej tsim nyog lossis cov tais cable los tiv thaiv cov xaim yog tias tsim nyog.
Fixture Assembly:Sib sau ua ke lub teeb siab bay teeb yog tias nws tuaj txog hauv qhov chaw. Qee qhov khoom siv yuav xav tau kho vajtse ntxiv rau kev teeb tsa.
Hanging Fixture:Nqa lub teeb ci ntsa iab rau ntawm lub mounting bracket. Ruaj ntseg nws nyob rau hauv qhov chaw uas siv cov cuab yeej muab (screws, bolts, thiab lwm yam). Xyuas kom tseeb tias lub fixture yog theem thiab kom raug.
Txuas Hluav Taws Xob Hluav Taws Xob:Txuas cov xaim los ntawm lub thawv sib txuas mus rau cov xaim ntawm lub teeb pom kev siab, sib txuam xim (yog tias tsim nyog) thiab ua kom muaj kev sib txuas ruaj ntseg. Siv cov txiv ntseej hlau los npog cov kev sib txuas uas raug thiab tom qab ntawd siv cov kab xev hluav taws xob ntxiv rau kev tiv thaiv ntxiv.
Kev kuaj:Thaum lub fixture tau ruaj ntseg txuas thiab xaim, tig lub hwj chim rov qab rau ntawm Circuit Court breaker los kuaj lub teeb. Xyuas kom tseeb tias lawv ua haujlwm kom raug ua ntej tawm hauv cheeb tsam.
Kev kho zaum kawg:Yog tias txhua yam ua haujlwm raws li qhov xav tau, koj tuaj yeem hloov kho zaum kawg rau lub kaum sab xis lossis txoj haujlwm ntawm lub teeb raws li xav tau.
Peb lub Hoobkas
Peb muaj cov pab pawg R & D muaj zog uas ua haujlwm ze rau Kev Lag Luam thiab Kev Muag Khoom, thiab kev tswj hwm nruj thiab cov chaw kom ntseeg tau tias qhov zoo, thiab peb tau tsim kev sib koom tes nrog cov khoom lag luam thoob ntiaj teb, xws li CREE, PHILIP LUMILEDS, NICHIA, MEANWELL, PHILIPS ect, peb tau teeb tsa peb tus kheej engineering chav kuaj kev nyab xeeb, xws li Photometric kuaj, EMI kuaj, EMC kuaj, Surge Test, ESD kuaj, IES cov ntaub ntawv thiab lwm yam.
FAQ
Q: Dab tsi yog lub neej ntev ntawm HB6 linear LED siab / qis bay teeb?
Q: Kuv yuav xaiv qhov zoo lumens tso zis rau kuv daim ntawv thov li cas?
Q: Puas yog HB6 linear LED siab / qis bay teeb dimmable?
Q: Cov teeb no puas tuaj yeem ntsia tau rau ntawm tus ncej?
Q: Dab tsi yog qhov txawv ntawm high bay thiab low bay teeb?
Q: Kuv yuav nruab HB6 linear LED siab / qis bay teeb li cas?
Q: Lub sijhawm lav rau HB6 linear LED siab / qis bay teeb yog dab tsi?
Q: Cov teeb no puas haum rau kev siv sab nraum zoov?
Q: Dab tsi qhov siab yog high bay LED mounting?
Lub teeb lub teeb siab feem ntau txhais tau tias yog lub teeb tsim los siv rau hauv qab nthab xws li 20-40 ko taw hauv qhov siab ntawm hauv pem teb. Lub siab bay qab nthab feem ntau pom muaj nyob rau hauv kev lag luam thiab qee qhov chaw lag luam.
Q: Kuv puas xav tau high bay teeb?
Q: Ntev npaum li cas High Bay LED teeb kav ntev?
LED high bay teeb yog ib qho kev xaiv zoo rau txhua daim ntawv thov uas yuav tsum tau ci ntsa iab, ua haujlwm zoo, thiab teeb pom kev zoo. Lawv tuaj yeem txuag koj txog li 80% ntawm cov nqi hluav taws xob piv rau cov teeb pom kev zoo ib txwm muaj, thiab lawv tuaj yeem kav ntev txog 50, 000 teev lossis ntau dua.
Q: Yuav ua li cas koj dai high bay LED teeb?
Clip lub nplhaib ntawm LED siab bay teeb rau hauv lub teeb nuv, thiab dai lub teeb los ntawm lub nplhaib; 3. Txuas cov hlua hluav taws xob los ntawm qhov chaw mus rau lub hwj chim qaum ntawm lub teeb, txuas nws raws li txoj cai ntawm kev xaim ntawm lub teeb, thiab cuam tshuam nrog cov khoom tsis muaj dej tsis zoo thiab insulating;
Q: Dab tsi yog LED high bay teeb siv rau?
Q: Kuv xav tau ntau npaum li cas high bay LED teeb?
Q: Qhov tsawg kawg nkaus qhov siab rau lub teeb qis qis yog dab tsi?
Q: Puas High Bay LED teeb tau kub?
Q: Koj puas tuaj yeem dim LED siab bay teeb?
Q: Koj puas tuaj yeem siv high bay teeb hauv chav nres tsheb?
Q: Muaj pes tsawg watts yog lub teeb ci siab?
Q: Dab tsi wattage LED rau qab nthab qhov siab?
Kev xaiv:
>Tsav Tsheb: Sosen, Meanwell ELG/HLG;
>Tswj thiab Dimming: 1-10V, DALI, Motion sensor, Hnub ci sensor, Zigbee thiab xwm ceev;
>Kev sib xyaw ua ke: 2 kab lossis 3 kab sib txuas nrog bracket;
>Lens: Symmetric 30 degree / 60 degree / 90 degree, Asymmeric 30 * 70 degree / 80 * 155 / 60 * 90 degree beam kaum sab xis;
>Installation: Ncua tseg, Phab ntsa Mounting;
>Factories / Warehouses / Supermarket
>Exhibitions / Showrooms / Tsiaj ua liaj ua teb
>Barns thiab Riding Halls / Logistic Center
>Chav tsev siab thiab chav tsev / chaw ntau pob / Tshuaj cog
>Tsob ntoo hloov
| Qauv No. | DR-LB050-FG1XX | DR-LB100-FG2XX | DR-LB150-FG3XX | DR-LB200-FG4XX | DR-LB300-FG3XDX |
| Qhov System Watts / W | 50W | 100W | 150W | 200W | 300W |
| System Efficiency/LPW | 140 LWB | ||||
| Lumen tso zis / lm | 7.000±5% | 14.000±5% | 21.000±5% | 28.000±5% | 42.000±5% |
| Rated Input Voltage / V | AC200 ~ 240V, 50/60Hz / (AC100 ~ 277V, 50/60Hz Yeem) | ||||
| LEDs Lub Teeb Source | SMD 3030 | ||||
| SDCM | <5 | ||||
| CCT/K | 5000K rau Standard (3000K / 4000K / 5700K / 6500K Yeem) | ||||
| CRI/Ra | >70Ra (>80Ra rau kev xaiv) | ||||
| Hwj chim Factor | >0.95 | ||||
| THD | <10% | ||||
| Beam Angle (yeem) | 30 degree / 60 degree / 90 degree / 30 * 70 degree / 80 * 155 / 60 * 90 degree Yeem | ||||
| UGR | <25 | ||||
| Kev tiv thaiv Surge | 6 ~ 10KV SPD ua hauv Tsav Tsheb, Sab Nrauv SPD 20KV Meanwell yeem | ||||
| LED tsav tsheb | Meanwell ELG/HLG, Sosen | ||||
| Kev ntsuas IP | IP65 | ||||
| Dimming (yeem) | 0/1-10V/DALI/Zigbee | ||||
| Sensor (yeem) | Motion Sensor, Hnub ci Sensor | ||||
| Kev kub ntxhov (yeem) | Muaj (30W @ 3Hrs rau Standard) | ||||
| Chav kawm tiv thaiv | Chav kawm Ⅰ | ||||
| Xim tiav (yeem) | Dub RAL9017 (Standard) / Dawb RAL9016 Yeem | ||||
| Khoom siv | Aluminium + PC (Toughened iav npog xaiv tau) | ||||
| Lifespan / teev | 70. 000 Hrs (Ta=30 degree @L70) | ||||
| Ua haujlwm Temp / degree | -40 degree rau + 50 degree (-40 degree F txog 122 degree F) | ||||
| Cia Temp / degree | - 40 degree rau + 65 degree (-40 degree F txog 149 degree F) | ||||
| Installation (yeem) | Loop Hanging, Qab nthab Mounting, Phab ntsa Mounting | ||||
| Daim ntawv pov thawj | CE (EMC + LVD), RoHS, ENEC, D-Mark, SAA, RCM Muaj | ||||
| Cwj pwm / hwj chim | 50W | 100W | 150W | 200W | 300W |  |
| A | 284.8mm ib | 5 42,9mm | 8 01mm | 1058.6 hli | 8 01mm | |
| B | 134mm ib | 134mm ib | 134mm ib | 134mm ib | 268mm ua | |
| C | 110.5 hli | 110.5 hli | 110.5 hli | 110.5 hli | 110.5 hli |
INSTALLATION GUIDE
COV NTAUB NTAWV TSEEM CEEB:
Thov nyeem tag nrho cov lus qhia hauv qab no ua ntej kev teeb tsa
>Nco ntsoov tias cov khoom siv hluav taws xob sib raug rau cov khoom ntsuas hluav taws xob;
>Cov khoom lag luam yuav tsum tau teeb tsa los ntawm tus kws tshaj lij hluav taws xob tsim nyog raws li National Electrical Code thiab cov cai hauv zos.
>Yog tias cov khoom puas lawm, tsis txhob siv nws!
TSEEM CEEB TSHAJ PLAWS - NYEEM thiab ua raws li tag nrho cov lus ceeb toom thiab cov lus qhia kev teeb tsa.
Khaws los yog muab rau tus tswv rau yav tom ntej siv.
Risk ntawm kev txiav:Hnav hnab looj tes tiv thaiv kev txiav los yog abrasions thaum tshem tawm ntawm lub thawv, tuav, txhim kho, thiab tswj cov khoom no.
Risk ntawm hluav taws xob shock:Cov khoom no yuav tsum tau muab tso rau hauv raws li txoj cai kev teeb tsa los ntawm ib tus neeg paub txog kev tsim kho thiab kev ua haujlwm ntawm cov khoom thiab cov kev phom sij cuam tshuam.
Risk ntawm Hluav Taws:Yam tsawg kawg 194 degree F muab cov khoom siv hluav taws xob. Tham nrog ib tus kws tshaj lij hluav taws xob tsim nyog kom paub meej tias cov ceg hluav taws xob raug cai.
DUALRAYS® xav tias tsis muaj lub luag haujlwm rau cov lus thov uas tshwm sim los ntawm kev teeb tsa tsis raug lossis tsis saib xyuas lossis tuav cov khoom no.
DALI Device
DALI Intelligent Control Diagram
DALI Intelligent Control Operator Interface
| Qauv No. | Net Nyhav / Kg | Ntim Cov Thawv Loj / hli | Qhov hnyav tag nrho / Kg | QTY"/CTN |
| DR-LB050-FG1XX | 8.3 | 325*490*380 | 9.2 | 4PCS / CTN |
| DR-LB100-FG2XX | 13.8 | 577*490*380 | 15.2 | 4PCS / CTN |
| DR-LB150-FG3XX | 19.5 | 828*490*380 | 21.2 | 4PCS / CTN |
| DR-LB200-FG4XX | 30.2 | 1180*490*380 | 32.4 | 4PCS / CTN |
| DR-LB300-FG3XDX | 39.5 | 828*980*380 | 42.4 | 2PCS / CTN |
